Copper Aluminium Hanging Portable Butt Welding Machine

Name: Copper Aluminium Hanging Portable Butt Welding Machine
Brand: Trintfar
Price: 4000 USD

Quality Copper Aluminium Hanging Portable Butt Welding Machine wholesale

Brand Name : Trintfar

Certification : CE

Place of Origin : China

MOQ : 1

Price : 4000~8000

Payment Terms : L/C, D/A, D/P, T/T

Delivery Time : 60~90

Packaging Details : Wooden brackets/wooden cases

Type : Flash Butt Welder

Reted Capacity : 50kVA-200kVA

Power(W) : Adjustable

Usage : Plastic Welding,plastic pipe butt fusion welding machine

Frequency : 50-60HZ,40KHZ,50HZ,50Hz / 60Hz,50Hz/60Hz

Contact Now

Product Description

Copper Aluminium Hanging Portable Butt Welding Machine

Item Model	UN-25	UN-35	UN-50	UN-75	UN-100	UN-150	UN-200
Rated capacity KVA	25	35	50	75	100	150	200
Rated Primary voltage V	380	380	380	380	380	380	380
Rated frequency Hz	50/60	50/60	50/60	50/60	50/60	50/60	50/60
Maximum short current A	11000	13000	15000	22000	28000	32000	35000
Maximum clamping rate N	3900	3900	3900	6100	6100	8000	8000
Maximum forging force N	1500	1500	1500	2500	2500	3000	3000
Rated duty cycle %	50	50	50	50	50	50	50

Feature

The power supply unit's duty are balanced. Three phase power make MD frequency inverter more adaptable in winding and pressure
of wire.
More preaser, faster current control, can analyse parameters more and faster compare with power frequency system.
Faster to set up current, the speed is 20folds quicker than traditional technic
Process more reliable: the majority of the application of solder DC welding metal effect will be even better.
Reduce operating costs, including energy savings each and every point of welding as well as shortening the welding cycle.
Save energy :especially suitable for welding thick workpieces and high-conductivity metal .such as aluminum and galvanized
steel sheet.etc.

Q Are you a trading company or a factory?
A We are an integrated industry and trade, and have our own factory.

Q Where is your factory located?
A Our factory is located in Songjiang district, Shanghai of China. In addition, we also have factories in Dongguan and Ningbo.

Q Can you customize the machine?
A We support OEM/ODM service and can customize the machine according to your requirements.

Q What is the MOQ?
A According to the customer's requirements.

Q What are your services during the purchase process?
A Pre-sales: Visit the factory, Technical solutions and program design services, Proofing services, Sample testing services.
On-sales: Technical training, Installation and commissioning services.
After-sales: Free non-wearable parts, Repair service, Video technical support, Online remote guidance.

Q How long is your warranty period?
A We offer a one-year warranty.

Q What is the payment terms?
A We ship with full payment, and we can negotiate payment terms.

Q How long is the delivery time?
A Delivery time for standard machines: 7-15 working days
