High Quality Steel Wire Butt Welding Machine Made in China

Name: High Quality Steel Wire Butt Welding Machine Made in China
Brand: Trintfar
Price: 2500 USD

Quality High Quality Steel Wire Butt Welding Machine Made in China wholesale

Brand Name : Trintfar

Certification : CE

Place of Origin : China

MOQ : 1

Price : 2500~10000

Payment Terms : L/C, D/A, D/P, T/T

Delivery Time : 45~60

Packaging Details : Wooden brackets/wooden cases

Easy Operation : Simplified controls for quick and efficient operation, ensuring user-friendliness.

High Efficiency : Consistent performance with a 50% duty cycle, minimizing downtime.

Durable Construction : Built to last with high-quality components, including a PLC, pressure vessel, and pump.

Versatile Application : Ideal for welding pipes in construction, manufacturing, and machinery repair sectors.

Reliable Warranty : Comes with a 3-year warranty on the main unit and a 1-year warranty on core components.

Application : Butt Welding Machine

Reted Capacity : 50kVA-200kVA

Voltage : 380V/220V

Color : Customized According Your Requirement

Power(W) : Adjustable

Contact Now

High Quality Steel Wire Butt Welding Machine Made in China

Item Model	UN-25	UN-35	UN-50	UN-75	UN-100	UN-150	UN-200
Rated capacity KVA	25	35	50	75	100	150	200
Rated Primary voltage V	380	380	380	380	380	380	380
Rated frequency Hz	50/60	50/60	50/60	50/60	50/60	50/60	50/60
Maximum short current A	11000	13000	15000	22000	28000	32000	35000
Maximum clamping rate N	3900	3900	3900	6100	6100	8000	8000
Maximum forging force N	1500	1500	1500	2500	2500	3000	3000
Rated duty cycle %	50	50	50	50	50	50	50

Feature

The power supply unit's duty are balanced. Three phase power make MD frequency inverter more adaptable in winding and pressure
of wire.
More preaser, faster current control, can analyse parameters more and faster compare with power frequency system.
Faster to set up current, the speed is 20folds quicker than traditional technic
Process more reliable: the majority of the application of solder DC welding metal effect will be even better.
Reduce operating costs, including energy savings each and every point of welding as well as shortening the welding cycle.
Save energy :especially suitable for welding thick workpieces and high-conductivity metal .such as aluminum and galvanized
steel sheet.etc.

High Quality Steel Wire Butt Welding Machine Made in China
Q Are you a trading company or a factory?
A We are an integrated industry and trade, and have our own factory.

Q Where is your factory located?
A Our factory is located in Songjiang district, Shanghai of China. In addition, we also have factories in Dongguan and Ningbo.

Q Can you customize the machine?
A We support OEM/ODM service and can customize the machine according to your requirements.

Q What is the MOQ?
A According to the customer's requirements.

Q What are your services during the purchase process?
A Pre-sales: Visit the factory, Technical solutions and program design services, Proofing services, Sample testing services.
On-sales: Technical training, Installation and commissioning services.
After-sales: Free non-wearable parts, Repair service, Video technical support, Online remote guidance.

Q How long is your warranty period?
A We offer a one-year warranty.

Q What is the payment terms?
A We ship with full payment, and we can negotiate payment terms.

Q How long is the delivery time?
A Delivery time for standard machines: 7-15 working days
